| 型 號Model |
ZP-5A |
ZP-7A |
ZP-9A |
| 轉臺沖模數 Number of Stations |
5 |
7 |
9 |
| 最大工作壓力 Max Main Pressure (KN) |
40 |
40 |
40 |
| 最大壓片直徑 Max Tablet Diameter (mm) |
12 |
12 |
12 |
| 最大片劑厚度 Max Tablet Thickness (mm) |
6 |
6 |
6 |
| 最大填充深度 Max Filling Depth (mm) |
15 |
15 |
15 |
| 最大壓片產量 Max Production Capacity (pcs/h) |
0.9 |
1.26 |
1.62 |
| 轉臺工作直徑 Turntable working diameter (mm) |
200 |
200 |
200 |
| 轉臺轉速 Max Turret Speed (r/min) |
0-30 |
0-30 |
0-30 |
| 中模直徑 In the mold diameter (mm) |
26 |
26 |
26 |
| 中模高度 In the mould height (mm) |
22 |
22 |
22 |
| 上下沖桿直徑 Upper and lower punch diameter (mm) |
22 |
22 |
22 |
| 上下沖桿長度 Upper and lower punch length (mm) |
115 |
115 |
115 |
| 外形尺寸 Overall Size (mm) |
450×635×1100 |
450×635×1100 |
450×635×1100 |
| 電動機功率 Motor Power (kw) |
1.5 |
1.5 |
1.5 |
| 電 壓The electric voltage (v) |
220V/380V |
220V/380V |
220V/380V |
